Introduction:
Features:
(1) With greater capacity and better screening efficiency, and the performance is at the most advanced level in China.
(2) The screen surface with greater acceleration improves the screening efficiency: the acceleration is greater than the bonding force to avoid material bonding, and the high acceleration (50G) makes the material to be screened completely loose and quickly separated, and there will be more fine particles through the screen.
(3) The deformable screen surface to prevent blocking mesh: especially under the high acceleration, the bouncing material flow is generated through the elastic sieve plate tension and relaxation to prevent particle adhesion. When the sieve plate is relaxed, the conical sieve becomes larger, effectively preventing particles close to the size of the sieve hole from blocking the sieve hole.
(4) Cone-shaped sieve holes to prevent blocking mesh: cone-shaped sieve holes to reduce the impact of blockage.
(5) Low frequency vibration can be superimposed to reduce the inclination angle of the screen machine.
(6) It can be completely sealed and effectively improves the working environment.
(7) Elastic sieve and sieve holes are not easy to block, no blockage, no bonding, and automatic cleaning of the screen plate.
(8) High amplitude jump, collision separation, impact through the screen, accelerate the loosening of the materials, and improve the screening efficiency.
(9) Long screen service life.
(10) The sieve can be made into a multi -layer screen surface.
Working Principle:
Technical Parameters:
Screen Width: 0.5m~3mm Screen Length: 2m~10m Separation Size: >3mm
| Model | Screen Area (㎡) | Layers of Screen | Angle (°) | Particle Size (mm) | Power (Kw) | Ref. Capacity (t/h) |
| ACS1340 | 5.2 | 1~3 | 16~35 | 3~20 | 18.5/37 | 60 |
| ACS1650 | 8 | 1~3 | 16~35 | 3~25 | 22/45 | 105 |
| ACS2055 | 11 | 1~3 | 16~35 | 3~30 | 22/45 | 120 |
| ACS2070 | 14 | 1~3 | 16~35 | 3~30 | 22/45 | 120 |
| ACS2465 | 15.5 | 1~3 | 16~35 | 3~35 | 30/55 | 120 |
| ACS2480 | 19 | 1~3 | 16~35 | 3~35 | 30/55 | 120 |
| ACS2790 | 24 | 1~3 | 16~35 | 3~42 | 30/55 | 260 |
| ACS3090 | 27 | 1~3 | 16~35 | 3~50 | 30/55 | 300 |
Application:
Applicable Materials:
Anthracite, ash, mature wood, recovered glass, basalt, crushed stone, mixed construction waste, aluminum-vanadium soil, pumice stone, biological waste, excavated earth, drilling mud, soil, silt, fine paper pulp, gypsum slurry, refuse fertilizer, magnesite, sea salt, slag, sintered coke, sintered ore, ooze (chalk mud, sewage mud, settling pond mud), crushed brick, brick powder, sugar etc.
| Material Type | Material | Separation Size | Humidity | Capacity |
| Gasification and power generation coal | Coal, brown coal | 6~8 or 10mm | 15~20% | 100~600 t/h |
| Coke for sintering and steelmaking | Coke | 3~6mm | 15~20% | 30~150 t/h |
| Hard rock | Calcite, dolomite, basalt, gabbro | 9~10mm | 2~15% | 20~300 t/h |
| Coal | Brown coal, hard coal | 2~40mm | 7~60% | 20~1200 t/h |
| Mixed fertilizer | Garbage compost, mature fertilizer | 4~20mm | 30~50% | 5~30 t/h |
| Slag | Blast furnace slag, iron slag, waste, incinerator furnace slag | 2~20mm | ~20% | 20~300 t/h |
| Coarse sand | Gravel, crushed stone, fine sand, natural sand | 2~15mm | ~10% | 20~300 t/h |
